| Quantity: | |
|---|---|
GTBZ18A1
Fullwon
| Item | Unit | Parameters |
| a Overall Length | mm | 9080 |
| b Overall Width | mm | 2490 |
| c Overall Height | mm | 2680 |
| d Wheel Base | mm | 2500 |
| Maximum Working Height | m | 20.1 |
| Maximum Platform Height | m | 18.4 |
| Maximum Working Range | m | 11.9 |
| Maximum Load Capacity | kg | 230 |
| 1st Boom Luffing Range | ° | 0～+70 |
| 2nd Boom Luffing Range | 0～+75 | |
| Crank Arm Luffing Range | -65～+70 | |
| Rotation Angle of Rotating Platform | ° | 360 |
| Maximum Tail Wagging | mm | 0 |
| Platform Size | mm | 1830×760 |
| Platform turning angle | ° | 180 |
| Total Weight | kg | 10600 |
| Maximum Travel Speed | km/h | 6 |
| Minimum Turning Radius | m | 6 |
| Minimum Ground Clearance | mm | 230 |
| Maximum Grade Ability | % | 45 |
| Tire Specification | - | 355/55D625 |
| Engine Model | - | Perkins 404D-22 |
| Rated Power of Engine | kW/(r/min) | 38/(3000) |
