SW350/SW354
Fullwon
| MAIN TECHNICAL PARAMETERS | |||
| Tractor Model | SW350 | SW354 | |
| Drive Type | 4X2 | 4X4 | |
| Overall Dimension L×W×H(mm) | 3590×1485×1940 | 3590×1485×1940 | |
| Wheel base(mm) | 1705 | 1760 | |
| Front wheel tread(mm) | 1100-1400 | 1200 | |
| Rear wheel tread(mm) | 1100-1400 | 1100-1400 | |
| Min. ground clearance(mm) | 380 | 280 | |
| Min. steering radius | Unilateral brake(m) | 2.8 | 2.8 |
| Not unilateral brake(m) | 3.2 | 3.4 | |
| Min. operating weight (KG) | 1480 | 1640 | |
| Gearbox gears number | 8F+4R | 8F+4R | |
| Speed | Forward(Kw/h) | 2.25-29.53 | 2.25-29.53 |
| Reverse(Kw/h) | 3.34-10.20 | 3.34-10.20 | |
| Engine | Model | YND490T-C053 | YND490T-C053 |
| Rated power (Kw) | 25.7 | 25.7 | |
| Rated speed (r/min) | 2200 | 2200 | |
| Tires spec. | Front tires | 5.50-16 | 7.50-16 |
| Rear tires | 11.2-28 | 11.2-28 | |
| Steering Type | Full hydraulic front wheels steering | ||
| Max. lifting force( KN ) | 5.8 | 5.8 | |
| PTO | Type | Rear-mounted, Non independent type | |
| Speed (r/min) | 540/720 or 540/1000 | 540/720 or 540/1000 | |
| Power(Kw) | ≥21.85 | ≥21.85 | |
| Control type of ploughing depth | Force control & Position control | ||
| Max. traction force (KN) | 5.8 | 6.9 | |
| Front / rear Ballast (KG) | 80/100 | 80/100 | |
| Notice: As our products will be improved continuously , all above parameters are subject to modification without notice. | |||
| MAIN FEATURES : | |||
300/350/304/354 wheeled tractors Main Features: 1. Adopt Yangdong diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency; 2. Gearbox using 4 × (2 +1) engaging sleeve, shuttle-type gearshift, there are 8 forward gears, 4 reverse gears, reasonable match between the gears, and have high efficiency; 3. Non independent power take off device, smooth transmission, large capacity, speed (540/720, 540/1000 r/min) for selection to meet the different operation requirements; 4. Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy; 5. Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good; 6. Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio; 7. New streamlined appearance, generous, modern, fashion; | |||
