120Hp Diesel Farm Tractor Supply by Fullwon

Drive Type : 4×4
Overall Dimension L×W×H: 4650×2038×2970 mm
Wheel base: 2449 mm
  • SW1204

  • Fullwon

Tractor Model  SW1204
Drive Type  4×4
Overall Dimension    L×W×H(mm)  4650×2160×2970
Wheel base(mm) 2449
Front wheel tread(mm) 1610
Rear wheel tread(mm) 1620-2020
Min. ground clearance(mm) 430
Min.  steering radius Unilateral   brake(m)  5.5±0.2
Min. operating weight (KG) 4550
Gearbox  gears number 16F+8R
Speed  Forward(Kw/h) 1.58-33.69
Reverse(Kw/h) 2.41-34.67
Engine Model LR6B5-23
Rated power (Kw) 88.2
type 6   cylinders, in line, water cooling, 4 strokes, direct injection, natural   aspiration
Rated speed (r/min) 2300
Tires spec. Front   tires 14.9-26
Rear tires 18.4-38
Steering Type Full   hydraulic  front wheels steering
Max. lifting force( KN ) 28
PTO Type 320/400
Speed (r/min) Height   control & flotation control
Power(Kw) Rear-mounted,   Independent type
Control type of ploughing depth 540/1000
Max. traction force (KN) 71.25
Front / rear Ballast (KG) 27
Notice: As our products will be improved continuously , all   above parameters are subject to modification without notice.
900/1000/1100/754/804/904/1004/1104 wheeled tractors
    Main Features:
    1. Adopt YTO diesel engine, good reliability, large reserves of torque, low   fuel consumption, high economic efficiency;
    2. Double-function clutch, operate independently, high transmission   capacity, effective and reliable, comfortable operation;
    3. Gearbox using 4 × (4+2)  engaging   sleeve, shuttle-type gearshift  , there   are 16 forward gears, 8reverse gears, reasonable match between the gears, and   have high efficiency;
    4. Independent power take off device, smooth transmission, large   capacity;
    5. Full hydraulic front wheels steering, independent oil circuit for steering   system, manipulating flexible, reliable, and save energy;
    6. Adopt hydrostatic disc-type brakes, a large braking torque, the braking   effect is good;
    7. Adopt high pressure type lifting device, reliable, easy maintenance,   multi-hydraulic output can be optioned;
    8. Final transmission adopts planetary gear mechanism, compact structure,   large reduction ratio;
    9. New streamlined appearance, generous, modern, fashion;
