SW300/SW304
Fullwon
MAIN TECHNICAL PARAMETERS | |||
Tractor Model | SW300 | SW304 | |
Drive Type | 4×2 | 4X4 | |
Overall Dimension L×W×H(mm) | 3535×1485×1895 | 3590×1485×1895 | |
Wheel base(mm) | 1705 | 1760 | |
Front wheel tread(mm) | 1100-1400 | 1200 | |
Rear wheel tread(mm) | 1100-1400 | 1100-1400 | |
Min. ground clearance(mm) | 338 | 235 | |
Min. steering radius | Unilateral brake(m) | 2.8 | 2.8 |
Not unilateral brake(m) | 3.2 | 3.4 | |
Min. operating weight (KG) | 1410 | 1620 | |
Gearbox gears number | 8F+4R | 8F+4R | |
Speed | Forward(Kw/h) | 2.07-27.08 | 2.07-27.08 |
Reverse(Kw/h) | 3.07-9.35 | 3.07-9.35 | |
Engine | Model | YD485T-C075 | YD485T-C075 |
Rated power (Kw) | 22.1 | 22.1 | |
Rated speed (r/min) | 2200 | 2200 | |
Tires spec. | Front tires | 5.50-16 | 6.50-16 |
Rear tires | 11.2-24 | 11.2-24 | |
Steering Type | Full hydraulic front wheels steering | ||
Max. lifting force( KN ) | 5 | 5 | |
PTO | Type | Rear-mounted, Non independent type | |
Speed (r/min) | 540/720 or 540/1000 | 540/720 or 540/1000 | |
Power(Kw) | ≥18.78 | ≥18.78 | |
Control type of ploughing depth | Force control & Position control | ||
Max. traction force (KN) | 5.6 | 6.7 | |
Front / rear Ballast (KG) | 80/80 | 80/80 | |
Notice: As our products will be improved continuously , all above parameters are subject to modification without notice. | |||
MAIN FEATURES : | |||
300/350/304/354 wheeled tractors Main Features: 1. Adopt Yangdong diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency; 2. Gearbox using 4 × (2 +1) engaging sleeve, shuttle-type gearshift, there are 8 forward gears, 4 reverse gears, reasonable match between the gears, and have high efficiency; 3. Non independent power take off device, smooth transmission, large capacity, speed (540/720, 540/1000 r/min) for selection to meet the different operation requirements; 4. Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy; 5. Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good; 6. Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio; 7. New streamlined appearance, generous, modern, fashion; |
MAIN TECHNICAL PARAMETERS | |||
Tractor Model | SW300 | SW304 | |
Drive Type | 4×2 | 4X4 | |
Overall Dimension L×W×H(mm) | 3535×1485×1895 | 3590×1485×1895 | |
Wheel base(mm) | 1705 | 1760 | |
Front wheel tread(mm) | 1100-1400 | 1200 | |
Rear wheel tread(mm) | 1100-1400 | 1100-1400 | |
Min. ground clearance(mm) | 338 | 235 | |
Min. steering radius | Unilateral brake(m) | 2.8 | 2.8 |
Not unilateral brake(m) | 3.2 | 3.4 | |
Min. operating weight (KG) | 1410 | 1620 | |
Gearbox gears number | 8F+4R | 8F+4R | |
Speed | Forward(Kw/h) | 2.07-27.08 | 2.07-27.08 |
Reverse(Kw/h) | 3.07-9.35 | 3.07-9.35 | |
Engine | Model | YD485T-C075 | YD485T-C075 |
Rated power (Kw) | 22.1 | 22.1 | |
Rated speed (r/min) | 2200 | 2200 | |
Tires spec. | Front tires | 5.50-16 | 6.50-16 |
Rear tires | 11.2-24 | 11.2-24 | |
Steering Type | Full hydraulic front wheels steering | ||
Max. lifting force( KN ) | 5 | 5 | |
PTO | Type | Rear-mounted, Non independent type | |
Speed (r/min) | 540/720 or 540/1000 | 540/720 or 540/1000 | |
Power(Kw) | ≥18.78 | ≥18.78 | |
Control type of ploughing depth | Force control & Position control | ||
Max. traction force (KN) | 5.6 | 6.7 | |
Front / rear Ballast (KG) | 80/80 | 80/80 | |
Notice: As our products will be improved continuously , all above parameters are subject to modification without notice. | |||
MAIN FEATURES : | |||
300/350/304/354 wheeled tractors Main Features: 1. Adopt Yangdong diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency; 2. Gearbox using 4 × (2 +1) engaging sleeve, shuttle-type gearshift, there are 8 forward gears, 4 reverse gears, reasonable match between the gears, and have high efficiency; 3. Non independent power take off device, smooth transmission, large capacity, speed (540/720, 540/1000 r/min) for selection to meet the different operation requirements; 4. Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy; 5. Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good; 6. Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio; 7. New streamlined appearance, generous, modern, fashion; |
