XG962H
Fullwon
| Manufacturer | XGMA | |
| Model | XG962H | |
| Overall length(mm) | 8820 | |
| Overall height(mm) | 3465 | |
| Overall width(mm) | 2835 | |
| Wheel base(mm) | 3300 | |
| Ground clearance(mm) | 435 | |
| Tread(mm) | 2240 | |
| Bucket Width (mm) | 3145 | |
| Turn radius(mm) | 6350 | |
| Min.Turn radius outside of bucket (mm) | 7470 | |
| 4225 | ||
| Max. Dumping Height(mm) | 3340 | |
| Dumping Reach(mm) | 1330 | |
| Digging depth(mm) | 60 | |
| Engine model | SC11CB240.1G2B1 | |
| Rated power (kw) | 175 | |
| Fuel comsumption per hour(g/kw.h ) | ≤225 | |
| Rated speed (r/min) | 2200 | |
| Max torque(N.m) | ≥1000 | |
| Operating Weight (Tonnes) | 20.4 | |
| Rated Load(Tonnes) | 6000 | |
| Bucket capacity (m3) | 2.6-5.5 | |
| Lifting time/Lifting, dumping and lowering(s) | 6.5/10.5 | |
| Max Breakout force(KN) | 175 | |
| Max.drawing force (KN) | 173 | |
| Max. turning angle(°) | 35 | |
| Climbing ability(°) | 28 | |
| Fuel tank（L） | 340 | |
| Hydraulic tank（L） | 305 | |
| Working pressure of steering hydraulic system(MPa) | 16 | |
| Working pressure of load hydraulic system(MPa) | 20 | |
| Travel speeds（km/h） | FORWARD 1ST | 0-6.7 |
| FORWARD 2ND | 0-11.8 | |
| FORWARD 3RD | 0-23.5 | |
| FORWARD 4TH | 0-37.6 | |
| REVERSE 1ST | 0-6.7 | |
| REVERSE 2ND | 0-10.6 | |
| REVERSE 3RD | 0-23.5 | |
| Gear Box | ZF | |
| Axle | XG | |
| Distibuting valve | D32 | |
| Steering Hydraulic system | BZZ6-1000 | |
| Tyre size | 23.5-25-20PR | |
| Air Conditioning/Anti-mist when idleing | yes | |
| Heating | yes | |
| Radio/Cassette | yes | |
| Bucket and arm raiseing (limit height) Device | yes | |
| Hydraulic Operation system | yes | |
| Seat Buckle | yes | |
| Head lamp | yes | |
| Reversing Alarm (Back vehicle) | yes | |
| ROPS/FOPS | yes | |
