Weichai Original Diesel Motor(WP10.336)

Product classIfication:Diesel Motor
Product Brand:Weichai
Product Model:WP10.336

Quantity:
  • WP10.336
  • Weichai
Motor WP10.336 Motor Brand Weichai
Series WP10 Motor Manufaturer Weichai Power
 Co., Ltd.
Adapation range Truck Motor Intake form Intercooler
 Cylinders Six Fuel Type Diesel
Cylinder
arrangement
Inline Displacement 9.726L
Emission Standard Euro 3 Maximum output
 power
247kW
Rated speed 2200rpm/1900rpm Maximum horse
power
336HP
Maximum torgue 1250Nm Maximum torque
speed
1200-1600rpm/
1350-1500rpm
Min fuel
consumption
196g/kW.h Motor form Water-cooled, four-stroke,
with exhaust valve brake,
direct injection,intercooler
Motor net weight 875kg Motor size 1525*730*1063mm
One meter away
noise
<104dB/104dB         Bore diameter
x stroke
126*130mm
Per cylinder valves 2
