Weichai Original Diesel Moto(WP10NG300E40)

Product classification:Diesel Motor
Product Brand:Weichai
Product Model:WP10NG300E40

Quantity:
  • WP10NG300E40
  • Weichai
Motor WP10NG300E40 Motor Brand Weichai
Series WP10NG Motor Manufaturer Weichai Power
 Co., Ltd.
Adapation
range
Heavy truck Intake form Intercooler
Cylinders 6 Fuel type LNG/CNG
Cylinders
Arrangement
Inline Displacement 9.726L
Emission Standard Euro 4 Max output
power
221kW
Rated speed 2200rpm Max horse
power
300HP
Max torque 1230N.m Max torque
speed
1400-1600rpm
Min fuel
consumption
185g/kW.h Motor form Water-cooled, wet cylinder liner, supercharged intercooler, electronically controlled premixing, spark plug ignition, lean burn
Motor net weight 870kg Motor size 1411*692*1122mm
Compression
ratio
11.5:1 Bore diameter x
stroke
126*130mm
Per cylinder valves 2 Ignition Order 1-5-3-6-2-4
