LG35B
Fullwon
| Model | LG35B | |
| Power type | Battery | |
| Rated capacity(Kg) | 3500 | |
| Jload centre(mm) | 500 | |
| h1STDMax.liftingheight(mm) | 3000 | |
| h3Freeliftingheight(mm) | 165 | |
| L5*W*TForksize(mm) | 1070×125×45 | |
| Masttiltangle(deg) | 6/12 | |
| L3Frontoverhang(mm) | 478 | |
| R1Min.turningradius(mm) | 2410 | |
| Min.width for pallets 1,000×1,200 crossways (L×W)(mm) | 4105 | |
| Min.width for pallets 800×1,200 lengthways (L×W)(mm) | 4305 | |
| Max.travelingspeed(km/h) | 15 | |
| Max.liftingspeed(mm/s)（load/unload） | 220/300 | |
| Max.gradient(load/unload)(%) | 12/15 | |
| STD Dead weight(kg) | 5250 | |
| S/PTread（front/rear）(mm) | 1000/980 | |
| L2Axledistance(mm) | 1700 | |
| Min.groundclearance, m1Frame(mm) | 130 | |
| Tire | Front | 28×9-15-14PR |
| Rear | 18×7-8-14PR | |
| Motor | Travel(AC)(kW) | 12 |
| Lift(AC)(kW) | 12 | |
| Battery(V/Ah) | 80/500 | |
| Working pressure (Mpa) | 17.5 | |
| Controller | ZAPI | |
