LG16BE
Fullwon
| Model | LG16BE | |
| Powertype | Battery | |
| Ratedcapacity(Kg) | 1600 | |
| JLoadcentre(mm) | 500 | |
| h1STDMax.liftingheight(mm) | 3000 | |
| h3Freeliftingheight(mm) | 145 | |
| L5*W*TForksize(mm) | 920×100×35 | |
| Masttiltangle(deg) | 6.5/6.5 | |
| L3Frontoverhang(mm) | 355 | |
| R1Min.turningradius(mm) | 1550 | |
| Min.width for pallets 1,000×1,200 crossways (L×W)(mm) | 3105 | |
| Min.width for pallets 800×1,200 lengthways (L×W)(mm) | 3305 | |
| Max.travelingspeed(km/h) | 13.5 | |
| Max.liftingspeed(mm/s)（load/unload） | 280/440 | |
| Max.gradient(load/unload)(%) | 15/15 | |
| STD Dead weight(kg) | 3100 | |
| S/PTread（front/rear）(mm) | 902/175 | |
| L2Axledistance(mm) | 1360 | |
| Min.groundclearance, m1Frame(mm) | 100 | |
| Tire | Front | 18×7-8 |
| Rear | 15×4.5-8 | |
| Motor | Travel(AC)(kW) | 4.5×2 |
| Lift(AC)(kW) | 10 | |
| Battery(V/Ah) | 48/500 | |
| Workingpressure(Mpa) | 14.5 | |
| Controller | ZAPI | |
