LG20BE
Fullwon
| Model | LG20BE | |
| Powertype | Battery | |
| Ratedcapacity(Kg) | 2000 | |
| JLoadcentre(mm) | 500 | |
| h1STDMax.liftingheight(mm) | 3000 | |
| h3Freeliftingheight(mm) | 145 | |
| L5*W*TForksize(mm) | 1070×120×40 | |
| Masttiltangle(deg) | 6.5/6.5 | |
| L3Frontoverhang(mm) | 355 | |
| R1Min.turningradius(mm) | 1658 | |
| Min.width for pallets 1,000×1,200 crossways (L×W)(mm) | 3213 | |
| Min.width for pallets 800×1,200 lengthways (L×W)(mm) | 3413 | |
| Max.travelingspeed(km/h) | 15 | |
| Max.liftingspeed(mm/s)（load/unload） | 250/440 | |
| Max.gradient(load/unload)(%) | 15/15 | |
| STD Dead weight(kg) | 3390 | |
| S/PTread（front/rear）(mm) | 924/175 | |
| L2Axledistance(mm) | 1466 | |
| Min.groundclearance, m1Frame(mm) | 100 | |
| Tire | Front | 200×50-10 |
| Rear | 15×4.5-8 | |
| Motor | Travel(AC)(kW) | 4.5×2 |
| Lift(AC)(kW) | 11 | |
| Battery(V/Ah) | 48/600 | |
| Workingpressure(Mpa) | 17.5 | |
| Controller | ZAPI | |
