6T/8T
ZOOMLION
| model | unit | DC60 | DC80 | |
| structure type | / | recirculating of batch type | recirculating of batch type | |
| machine weight | kg | 2650 | 2650 | |
| Batch type capacity | rice（0.56T/m3） | kg | 8000 | 8000 |
| capacity | （dropping extent 25 % to 15%） | kg/h | ≥400 | ≥400 |
| Overall dimension(L*W*H) | mm | 3478 *3004 *6531 | 3478 *3004 *7076 | |
| heating model | / | direct heating/indirect heating | ||
| fuel | / | Diesel, rice hull, gas, biomass particles, etc | ||
| power | Rated Voltage | v | Three-phase 380V/50HZ/One-phase220V/60HZ/Three-phase220V/60HZ | |
| total power | kw | 6.94 | 6.94 | |
| performance | feed time：rice/wheat | min | 50～60/45～55 | 50～60/45～55 |
| unloading time：rice/wheat | min | 45～55/40～50 | 45～55/40～50 | |
| hot air temp | ℃ | 30～100 | 30～100 | |
| rainfall rate | %/h | 0.5～1.2 | 0.5～1.2 | |
| drying capacity | t•%/h | ≥3 | ≥3 | |
| drying uneven rate | % | ≤1 | ≤1 | |
| safety device | / | Wind pressure switch, hot air temperature sensor, abnormal overheat switch, | ||
| thermal relay, circuit breaker, full alarm switch. | ||||
| model | unit | DC60 | DC80 | |
| structure type | / | recirculating of batch type | recirculating of batch type | |
| machine weight | kg | 2650 | 2650 | |
| Batch type capacity | rice（0.56T/m3） | kg | 8000 | 8000 |
| capacity | （dropping extent 25 % to 15%） | kg/h | ≥400 | ≥400 |
| Overall dimension(L*W*H) | mm | 3478 *3004 *6531 | 3478 *3004 *7076 | |
| heating model | / | direct heating/indirect heating | ||
| fuel | / | Diesel, rice hull, gas, biomass particles, etc | ||
| power | Rated Voltage | v | Three-phase 380V/50HZ/One-phase220V/60HZ/Three-phase220V/60HZ | |
| total power | kw | 6.94 | 6.94 | |
| performance | feed time：rice/wheat | min | 50～60/45～55 | 50～60/45～55 |
| unloading time：rice/wheat | min | 45～55/40～50 | 45～55/40～50 | |
| hot air temp | ℃ | 30～100 | 30～100 | |
| rainfall rate | %/h | 0.5～1.2 | 0.5～1.2 | |
| drying capacity | t•%/h | ≥3 | ≥3 | |
| drying uneven rate | % | ≤1 | ≤1 | |
| safety device | / | Wind pressure switch, hot air temperature sensor, abnormal overheat switch, | ||
| thermal relay, circuit breaker, full alarm switch. | ||||
