Sinotruk hohan 6x4
Fullwon
Sinotruk hohan 6x4 dump truck Basic data | |
Wheel base(mm) | 3800+1350 |
Dimension(mm) | 8550x2496x3450 |
Tread | 2041mm(front), 1830mm |
Curb Weight(kg) | 12100 |
Loading Capacity(kg) | 12770 |
GVW(kg) | 25000 |
Approach angle | 20° |
Departure angle | 20° |
Tipper box | |
Dimension(mm) | 5800x2300x1160 |
Type of tipper box | Rear dump |
Engine | |
Engine model | SINOTRUK Engine,Euro II / Euro III/ Euro IV / Euro V |
Power | 266HP/290HP/336HP/371HP/420HP 280HP/310HP/340HP/380HP |
Number of cylinder | 6 |
Fuel | Diesel |
Engine type | Inline 6 cylinder, water cooling |
4-stroke, inter-cooling, high pressure common rail | |
Transmission | |
Transmission model | Sinotruk HW19710/HW15710 |
Front gear | 10 |
Reverse gear | 2 |
Tire | |
Number of Tire | 10 |
Tire type | 11.00-20/12.00-20 Nylon 11.00R20 Radial 295/80R22.5 tubless tires |
Fuel tank | |
Fuel tank capacity | 400L |
Chassis | |
Rear axle | ST16 bipolar deceleration drive axle |
Loading capacity of rear axle | 16000 kg |
Lift system | front/middle lift |
Tipper capacity | 18-22m3 |
Thickness of the Plates | Bottom: 8, Side: 6; Bottom: 8; Side: 4 |
Leaf spring | 10/12 |
