SRSC1009-6E
SANY
| Configuration | Engine manufacturer | CUMMINS QSB6.7 |
| Rated power | 164/2300kW/rpm | |
| Max.torque | 949/1400Nm/rpm | |
| Emission standard | Tier III | |
| Transmission | CLARK 13.7HR32334 | |
| Drive axle | Kessler D81 PL488 | |
| Tire | 14.00-24 28PR | |
| Spreader | Model | SDJE100 |
| Side shift range | ±800mm | |
| Rotation angle | +105°/-195° | |
| Self weight | 4.7t | |
| Application | ISO 20'/40'/45' | |
| Boom | Max.lifting height | 16200mm |
| Boom tilt angle | 0°-64.5° | |
| Performance | Max.lifting speed (non-load/load) | 450/400mm/s |
| Max.lowering speed (non-load/load) | 400/400mm/s | |
| Max.travel speed (non-load/load) | 28/25km/h | |
| Gradeability (non-load/load) | 33/27% | |
| Hydraulic system work pressure | 220bar | |
| Overall weight | 39t | |
| Max.load | 10t | |
| Stacking height | 6(8'6") | |
| Overall length | 11000mm | |
| Wheel base | 5000mm | |
| Overall height | 4000mm | |
| Min.ground clearance | 250mm | |
| Overall width | 6053-12185mm | |
| Front wheel width | 3280mm | |
| Rear wheel width | 2450mm | |
| Min.turning radius | 6800mm | |
| 20”container aisle width | 10000mm | |
| 40”container aisle width | 13600mm |
