XCMG Mobile Crane QY20B.5 Supply by Fullwon

Overall length: 12400 mm
Overall width: 2500 mm
Overall height: 3300 mm
Availability:
Quantity:
  • QY20B.5

  • Fullwon

Dimension Unit QY20B.5
Overall length mm 12400
Overall width mm 2500
Overall height mm 3300
Weight

Total weight in travel kg 26020
Front axle load kg 6900
Rear axle load kg 19120
Power

Engine model
 SC8DK260Q3,   WD615.327
Engine rated power kW/(r/min) 192/2200       198/2200
Engine rated torque N.m/(r/min)  1100/1400       1150/1400
Travel

Max. travel speed km/h 75
Min. turning diameter m 20
Min. ground clearance mm 270
Approach angle ° 21
Departure angle ° 11
Max. grade ability % 35
Fuel consumption for 100km L ≈35
Main performance

Max. rated total lifting capacity t 20
Min. rated working radius mm 3000
Turning radius at turntable tail m 3.385
Max. lifting torque kN.m 860
Base boom m 10.06
Fully extended boom m 32.76
Fully extended boom+jib m 42.12
Longitudinal outrigger span m 4.97
Lateral outrigger span m 5.4
Working speed

Boom luffing time s 75
Boom full extension time s 95
Max. swing speed r/min 3
Max. speed of main winch (single rope) m/min 100
Max. speed of aux. winch (single rope) m/min 100
