XCMG Mobile Crane QY16C Supply by Fullwon

Overall length: 11990 mm
Overall width: 2500 mm
Overall height: 3350 mm
  • QY16C

  • Fullwon

Classificatory Item Unit Parameter
Engine Model
Outline dimension Overall   length mm 11990
Overall width mm 2500
Overall height mm 3350
Wheel base Axle   1, Axle 2 mm 4025
Axle 2, Axle 3 mm 1350
Mass Total   mass in travel state kg 22900

Axle   1 kg 5240
Axle load Axle   2 kg 17660
Travel performance Travel   speed Max.   travel speed km/h 70
Min. stable travel speed km/h 4
Turning diameter Min.   turning diameter m 20
Min. turning diameter at boom tip m 23
Min. ground clearance mm 270
Approach angle (°) 21
Departure angle (°) 10
Braking distance (at 30km/h with full load) m 9.5
Max. grade-ability 24
Fuel consumption for 100km L 35
Power Engine   rated output kW/(r/min) 158/2200
Engine rated torque N.m/   (r/min) 790/1400
Engine rated speed r/min 2200

Main Technical Data for Lifting Operation

Classificatory Item Unit Parameter
Lifting performance Max.   total rated lifting capacity t 16
Min. rated working radius m 3
Turning radius at turntable tail m ≤3.12
Max. load moment Base   boom kN.m 711
Fully extended boom kN.m 449
Fully extended boom + Jib kN.m 186
Outrigger span Longitudinal m 4.6
Lateral m 5.4
Lifting height Base   boom m ≥9.9
Fully extended boom m ≥23.6
Fully extended boom + Jib m ≥30.8

Boom   raising time s ≤60
Working speed Boom   full extension time s ≤75

Max.   swing speed r/min ≥2.5

Hoist   speed Main   winch Full   load m/min ≥54

(single   line) No   load m/min ≥100

Aux.   winch Full   load m/min ≥54

No   load m/min ≥100
Noise limit Crane   exterior noise dB   (A) ≤118
At seated position dB   (A) ≤90
