RP601
Fullwon
| Items | Unit | Parameters |
| Basic paving width | m | 2.5 |
| Max. paving width | m | 6 |
| Max. paving thickness | mm | 150 |
| Paving speed | m/min | 0～3.6 |
| Travel speed | km/h | 0～11 |
| Theoretical Productivity | t/h | 300 |
| Hopper Capacity | t | 13 |
| Gradeability | % | 20 |
| Pavement evenness | mm/3m | 3 |
| Transverse levelling accuracy | % | ±0.03 |
| Centre crown ratio | % | 0～+3 |
| Engine model | D4114ZG2B | |
| Engine power | kW | 100 |
| Engine speed | r/min | 2400 |
| Machine weight | t | 17.4 |
| Dimension | mm | 6400X2580X3830 |
| Vibrator speed | r/min | 0～1470 |
| Screed heating | Gas heating | |
| Auger and conveyor control | Automatic Control by Ultrasonic Sensors | |
| Automatic levelling control | Simulation control of electronic automatic leveler | |
| Items | Unit | Parameters |
| Screed model | / | 475Q |
| Type | / | Single vibrator+Gas heating |
| Extension | / | Hydraulic+Mechanical assembly |
| Width | / | 2.5～6.0 |
| Vibrator speed | r/min | 0～1470 |
| Vibrator amplitude | mm | 4 |
| Extra-long screed | mm | 625 |
| Items | Unit | Parameters |
| Basic paving width | m | 2.5 |
| Max. paving width | m | 6 |
| Max. paving thickness | mm | 150 |
| Paving speed | m/min | 0～3.6 |
| Travel speed | km/h | 0～11 |
| Theoretical Productivity | t/h | 300 |
| Hopper Capacity | t | 13 |
| Gradeability | % | 20 |
| Pavement evenness | mm/3m | 3 |
| Transverse levelling accuracy | % | ±0.03 |
| Centre crown ratio | % | 0～+3 |
| Engine model | D4114ZG2B | |
| Engine power | kW | 100 |
| Engine speed | r/min | 2400 |
| Machine weight | t | 17.4 |
| Dimension | mm | 6400X2580X3830 |
| Vibrator speed | r/min | 0～1470 |
| Screed heating | Gas heating | |
| Auger and conveyor control | Automatic Control by Ultrasonic Sensors | |
| Automatic levelling control | Simulation control of electronic automatic leveler | |
| Items | Unit | Parameters |
| Screed model | / | 475Q |
| Type | / | Single vibrator+Gas heating |
| Extension | / | Hydraulic+Mechanical assembly |
| Width | / | 2.5～6.0 |
| Vibrator speed | r/min | 0～1470 |
| Vibrator amplitude | mm | 4 |
| Extra-long screed | mm | 625 |
