SQ16ZK4Q
Fullwon
| Model | SQ16ZK4Q | Unit | ||||
| Max Lifting Moment | 40 | t.m | ||||
| Max Lifting Capacity | 16000 | kg | ||||
| Recommend Power Needed At Recommend Oil Flow | 37 | kw | ||||
| Max Oil Flow of Hydraulic System | 63 | L/min | ||||
| Rated Pressure Of Hydraulic System | 31.5 | MPa | ||||
| Oil Tank Capacity | 250 | L | ||||
| Rotation Angle | (360°) All Rotation | |||||
| Crane Weight | 5000 | kg | ||||
| Installation Space | 1500 | mm | ||||
| Choice of Chassis | NXG1310D3ZEX; BJ1317VNPJJ-S5; DFL1311A3 ; | |||||
| SQ16ZK4Q Lifting capability diagram | ||||||
| Working radius(m) | 2.5 | 4.098 | 5.898 | 7.748 | 9.618 | 11.518 |
| Lifting capacity(kg) | 16000 | 9600 | 6600 | 4850 | 3500 | 2600 |
