SW3B3523102
Fullwon
Product name | 3 wheels truck/tricycle with sun shade | ||
Model | SW3B3523101 | ||
Cabin | Jinyunhu wind shield | ||
Main dimensions | Overall dimensions (LxWxH)mm | (mm) | 4030×1580×2085 |
Dimensions of the cargo body (LxWxH)mm | (mm) | 2300×1500×(380+350) | |
Wheel base | (mm) | 2645 | |
Wheel track (front/rear) | (mm) | 1210 | |
Min. ground clearance | (mm) | 260 | |
Weight | Curb weight | (kg) | 1210 |
Rated payload | (kg) | 3000 | |
Persons in cab | (persons) | 2 | |
Gross vehicle weight | (kg) | 4340 | |
Overall performance | Max. speed | (km/h) | 44.5 |
Max. slope of climb | (%) | 15 | |
Min. turning radius | (m) | 3.7 | |
Engine | Engine Type | CCZS1115 | |
Displacement | (L) | 1.194 | |
Rated horsepower | (kg.m/rpm) | 22 | |
Steering gear Type | Mechanical | ||
Service brake and boostingType | Oil brake | ||
Wheels and tire sizes | Front wheel | 6.00-14 | |
Rear wheel | 7.00-16 | ||
Electric device | Rated voltage | V | 12 |
Battery | 6-QW-120MF |
