full flat bed trailer
Fullwon
Chassis and main parts | |
DIMENSION | 12450mm*2490mm*1557mm,Size can be design depends on customers' request |
AXLES | 13 T/PER axle, FUWA /BPW/HJ brands for choose |
RIM | 9.00-22.5 13PCS or other sizes |
TIRE | 12R22.5-22.5 13 PCS or other sizes ,Triangle/Double Coin/Linglong |
SUSPENSION | Mechanical suspension or Airbag suspension |
LEAF SPRING | 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 Layer |
KINGPIN | JOST brand 2.0 or 3.5inch bolts type or turntable (diameter is 1.1m) |
DRAW BAR | 4*4 or 4*6mm square tube (lengthis 1.4m ) or design and make depends on request |
TRACTOR HOOK | DN50 |
MAIN BEAM | Height: 450mm-520mm, upper plate is 14mm-16mm, middle plate is 8mm-12mm, |
down plate is 16mm-20mm ; Material is Q345B standard steel . | |
SIDE BEAM | 16mm -25mm channel steel (Material is Q235B standard steel ). |
PLATFORM | Standard 3 mm thickness checkered plate |
SIDE WALL | Can be fixed with 600mm-1200mm side door |
BRAKING SYSTEM | WABCO brand emergency valve, T30/30+T30 Spring brake chamber, one piece of45L air tank , ABS is optional |
TWIST LOCKS | Can be fixed with 4 or 8 or 12PCS (lift and screw type for choose) |
ELECTRIC SYSTEM | Voltage is 24V / 7 ways (7 wire harness) / LED light |
TOOL BOX | One piece ,equipped with 1 unit Tire spanner,1 piece sleeve and 1 piececranking bar) |
PAINTING | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
OTHERS | Design and make the right trailer depends on customers' request |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Shipping Terms | By bulk cargo carrier |
Chassis and main parts | |
DIMENSION | 12450mm*2490mm*1557mm,Size can be design depends on customers' request |
AXLES | 13 T/PER axle, FUWA /BPW/HJ brands for choose |
RIM | 9.00-22.5 13PCS or other sizes |
TIRE | 12R22.5-22.5 13 PCS or other sizes ,Triangle/Double Coin/Linglong |
SUSPENSION | Mechanical suspension or Airbag suspension |
LEAF SPRING | 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 Layer |
KINGPIN | JOST brand 2.0 or 3.5inch bolts type or turntable (diameter is 1.1m) |
DRAW BAR | 4*4 or 4*6mm square tube (lengthis 1.4m ) or design and make depends on request |
TRACTOR HOOK | DN50 |
MAIN BEAM | Height: 450mm-520mm, upper plate is 14mm-16mm, middle plate is 8mm-12mm, |
down plate is 16mm-20mm ; Material is Q345B standard steel . | |
SIDE BEAM | 16mm -25mm channel steel (Material is Q235B standard steel ). |
PLATFORM | Standard 3 mm thickness checkered plate |
SIDE WALL | Can be fixed with 600mm-1200mm side door |
BRAKING SYSTEM | WABCO brand emergency valve, T30/30+T30 Spring brake chamber, one piece of45L air tank , ABS is optional |
TWIST LOCKS | Can be fixed with 4 or 8 or 12PCS (lift and screw type for choose) |
ELECTRIC SYSTEM | Voltage is 24V / 7 ways (7 wire harness) / LED light |
TOOL BOX | One piece ,equipped with 1 unit Tire spanner,1 piece sleeve and 1 piececranking bar) |
PAINTING | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
OTHERS | Design and make the right trailer depends on customers' request |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Shipping Terms | By bulk cargo carrier |
