bottom discharge bulk cement tanker semi trailer
Fullwon
| Tare Weight | About 10.5T |
| Dimension | 11500mm*2490mm*3750mm |
| Loading Capacity (T) | 48T |
| Axle | 3 axles 13 T/Guangdong FUWA |
| Rim | 9.00-22.5 (special for export market) |
| Tire | 12R22.5 Triangle brand 13pieces |
| Suspension | Mechanical suspension ( Mechanical America Type optional) |
| Spring leaf | 90(W)mm*13(Thick)mm*10 Layer |
| King pin | brand JOST 2.0inch or 3.5inch |
| Support leg | Jost brand |
| Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, |
| Down plate is 16mm; Material is Q345B Steel | |
| Tanker body material | 5or6 mm/Q235 |
| End plate | 5 or 6 mm/Q235 |
| Diesel Engine | WEICHAI, Tianhe 4102 |
| Brake chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber ; One piece of 45L air tanks |
| ABS | Without (optional) |
| Compressor | BOHAI 12m3 or other brand |
| Valve | WABCO valve |
| Light | LED light |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Tool box | 1 piece:equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive primer, 2 coats of final paint |
| Shipping Terms | By bulk cargo carrier, RORO, 40 flat rack |
