10T/15T
ZOOMLION
Sales identification number | DC100 | DC125 | DC150 | ||||
Model | 5HXG-10C | BHXG-12.5C | 5HXG-15C | ||||
Structural style | Batch-type circulation | ||||||
Total weight | 2840 | 3040 | 3240 | ||||
Capacity(kg) | Unhusked rice(0.56T/m³) | 2500~10000 | 2500~12500 | 2500~15000 | |||
Wheat(0.68T//m³) | 3035~12100 | 3035~15200 | 3035~18200 | ||||
Processing amount (kg/h)( moisture reduction rate of 25% to 14.5%) | ≥600 | ≥800 | ≥900 | ||||
Overall size | Overall length | 3577 | 3577 | 3577 | |||
Overall width | 2973 | 2973 | 2973 | ||||
Overall height | 9315 | 10405 | 11495 | ||||
Heating mode | Direct/Indirect | ||||||
Burner | Type | Double fire control,and double throttle automatic adjustment | |||||
Lgnition mode | High voltage autoigtion | ||||||
Fuel type | Natural gas~liquefied gas | ||||||
Fuel consumption(kg/h) | 8Nm³/h<gas consumption<15Nm³ | ||||||
Total power(kW) | 9.44 | ||||||
Mating power | Three-phase 380V/50HZ | ||||||
Applicable fuel type | Bio-particles, rice husk, natural, gas, liquefied gas, diesel, electric power ,etc | ||||||
Performances | Feeding time: rice/wheat(min) | 40~50/35~45 | 50~60/40~50 | 55~65/50~60 | |||
Discharging time: rice/wheat(min) | 50~60/45~55 | 60~70/55~65 | 70~80/65~75 | ||||
Hot air temperature(℃) | 30~120 | ||||||
Moisture reduction rate(%/h) | 0.5~1.2 | ||||||
Drying capacity(t/h*%/h) | Rice≥6/ wheat≥7 | ||||||
Unit heat consumption(KJ/kg. water | ≤5000 | ||||||
Safety devices | Air pressure switch, hot Air temperature sensor, malfunction overheat switch, hot relay, breaker protector, full-load alarm | ||||||
