SR20-5
Fullwon
| Performance Parameters | |||
| Length × width × height (mm) | 6501×3151×2402 | Total weight (kg) | 20000/20200 |
| Front wheel weight (kg) | 13000/13200 | Theoretical gradeability (%) | 45 |
| Vibratory drum width (mm) | 2140 | Static linear load (N/cm) | 595/605 |
| High vibration amplitude | 1.85/1.8 | Low vibration amplitude | 1.05/1.0 |
| Vibration frequency (high/low) (Hz) | 32/28 | Centrifugal force (high/low) (kN) | 345/255 |
| Engine model | Cummins 6CTAA8.3-C215 |
| Performance Parameters | |||
| Length × width × height (mm) | 6501×3151×2402 | Total weight (kg) | 20000/20200 |
| Front wheel weight (kg) | 13000/13200 | Theoretical gradeability (%) | 45 |
| Vibratory drum width (mm) | 2140 | Static linear load (N/cm) | 595/605 |
| High vibration amplitude | 1.85/1.8 | Low vibration amplitude | 1.05/1.0 |
| Vibration frequency (high/low) (Hz) | 32/28 | Centrifugal force (high/low) (kN) | 345/255 |
| Engine model | Cummins 6CTAA8.3-C215 |
