Tare Weight | About 7.6T |
Dimension | 13000mm*2490mm*2860mm |
Loading Capacity (T) | ≤ 60 T |
Axle | 13T, FUWA /BPW /Huajing Brand |
Rim | 9.00-22.5 |
Tire | 12.00R22.5 |
Suspension | Mechanical suspension (America Type) |
Spring leaf | 90(W)mm*13(Thickness)mm*10 Layer |
King pin | JOST brand 2.0 or 3.5inch bolts type |
Support leg | China brand 28Tons (Double speed) |
Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, |
down plate is 16mm ; Material is Q345B Steel . | |
Side beam | 16mm ( Material is Q235steel ). |
Side Wall | 1800mm |
Brake chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand);one piece of 45L air tanks |
ABS | Without |
Valve | WABCO valve |
Light | LED light |
Voltage | 24V |
Receptacle | 7 ways (7 wire harness) |
Tool box | One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Shipping Terms | By bulk cargo carrier |
