Availability: | |
---|---|
Quantity: | |
SPECIFICATION | ||
ITEM | DATA | |
Recommended Hole size range | Hole size range | Ø 90 - 130 mm |
Hammer Sizes | 3.5 inches / 4 inches | |
Drill Rod ( Pipe ) Handling system ( RHS ) | Pipe Handling System | 7+1 |
Drill Pipe dia | 68 mm / 76 mm | |
Drill Pipe Length | 3.5m | |
Max. Hole Depth w/ auto RHS | 28m | |
Hydraulic Rotary Head | Rotation Speed | 0 - 105 rpm |
Max. Work Torque | 2,800 Nm | |
Engine | Cummins QSC8.3 | |
Rated Power | 194 kW @ 2,200 rpm | |
Emission Standard | Stage 3 | |
Fuel Tank | Size | 350L |
Compressor | JE810Ⅱ | |
Max. Work Pressure | 20 Bars | |
FAD | 16 m³ / min | |
Boom Type | Heavy duty straight | |
Feed Beam | Feed type | Motor - chain |
Total Length | 6,865 mm | |
Feed travel length | 4,100 mm | |
Feed extension | 1,200 mm | |
Max. Feed speed | 0.85 m / s | |
Max. Feed force | 15 kN | |
Max. Pull up force | 31 kN | |
Chassis | Max. tramming speed | 3 km / h |
Max. Traction force | 115.4 kN | |
Slope Capability | 30º (add winch if >20º) | |
Track Frame Oscillation | +/- 10° | |
Ground Clearance | 450 mm | |
Transportation Dimensions ( w/o options ) about | Weight | 15,000 kg |
Width | 2,480 mm | |
Length | 9,980 mm | |
Height | 3,200 mm |
