SDCY90K8H3
SANY
| Configuration | Engine manufacturer | VOLVO TAD871VE |
| Rated power | 185/2200kw/rpm | |
| Max torque | 1160/1200Nm/rpm | |
| Emission standard | Tier 4 | |
| Transmission | CLARK 13.7HR32000 | |
| Drive axle | KESSLER D81 PL488 | |
| Spreader model | SDJ90II | |
| Side shift range | ±600mm | |
| Application | ISO20'/40' container | |
| Tire | 14.00-24 28PR | |
| Performance | Overall weight | 41t |
| Max loading capacity | 9t | |
| Stacking height | 8(8'6'') | |
| Max lifting speed(non-load/load) | 600/550mm/s | |
| Max lowering speed(non-load/load) | 550/600mm/s | |
| Max travel speed(non-load/load) | 28/26km/h | |
| Gradeability(non-load/load) | 30/22% | |
| Main parameters | Overall length | 6900mm |
| Load center | 1220mm | |
| Wheel base | 4550mm | |
| Front overhang | 1140mm | |
| Mast height(retracted/extended) | 12315/21740mm | |
| Min ground clearance | 320mm | |
| Min lifting height | 2250mm | |
| Max lifting height | 21250mm | |
| Min turning radius | 6000mm | |
| 20'' container aisle width | 10000mm | |
| 40'' container aisle width | 14000mm | |
| Overall width | 6038-12170mm | |
| Front wheel width | 3280mm | |
| Rear wheel width | 2150mm | |
| Sloping angle(front/rear) | 2/4° |
